Kink worked closely with Hobie Doan on his signature Roll Up frame to give him all the specs and features he was looking for in a super tough frame. The investment cast chainstay yoke creates a clean look. while providing extra stiffness and a ton of tyre clearance. For the seatstay bridge the frame features an oversized laser cut bridge for more stiffness and a great look. Modern street geometry throughout the frame of course. with a 75° headtube angle and 12.75 chainstay length. The dropouts feature a revised shape based on Hobie's input and feature integrated chain tensioners to ensure your wheel stays in place and chain stays tight. This frame includes removable brake mount hardware and an integrated seat post clamp with a handy 5mm/6mm combo bolt.

###section###

Product Specs

1. MATERIAL: Chromoly
2. HEAD TUBE ANGLE: 75°
3. SEAT TUBE ANGLE: 71°
4. CHAIN STAY LENGTH: 12.75
5. BB HEIGHT: 11.75
6. WHEEL SIZE: 20
7. STANDOVER HEIGHT: 9.25
8. DROPOUT SIZE: 14mm
9. HEADSET TYPE: Intergrated
10. BB TYPE: Mid
11. BRAKE MOUNTS: Removable (Included)
12. GYRO TABS: None
13. WEIGHT: 5lbs

###section###

Product Highlights

• Responsive Geometry with Short Backend and Steep Headtube
• Best suited to Street and Park riding
• High-quality Chromoly construction
• Strong and durable investment cast chainstay yoke
• Built in chain tensioners
